PRO INDOOR SERIES

Precision direct view LED for environments where image accuracy matters most. The Pro Indoor Series is manufactured in Korea with premium COB technology to deliver exceptional color uniformity, 15,000:1 contrast, and dependable performance for demanding applications.

WHEN EVERY PIXEL MATTERS

The Pro Indoor Series is precision manufactured in Korea using premium components and Flip-Chip COB technology to deliver exceptional color uniformity, surface flatness, and durability. With 15,000:1 contrast, minimal glare and color distortion, and multiple fine pixel pitch options, Pro is made for demanding environments where visual accuracy can’t be compromised.

01

DESIGNED FOR VISUAL PRECISION

→ Color Accuracy

Premium COB technology delivers deep blacks, broad color coverage, and a 15,000:1 contrast ratio for remarkably accurate imagery.

→ Surface Uniformity

Precision tolerances create exceptional surface flatness and consistent image quality across the entire display.

→ Reduced Glare

Minimal glare and color distortion help preserve clarity and detail in demanding viewing environments.

→ Wide Viewing

A 178° viewing angle maintains consistent color and image quality from nearly anywhere in the room.

02

ENGINEERED FOR ALWAYS-ON RELIABILITY

→ Available Redundancy

Optional redundant power supplies, receiving cards, and controllers provide added confidence for always-on applications.

→ Front Serviceable Design

Complete front access provides greater installation flexibility while making routine maintenance faster and less disruptive.

→ Power Efficiency

Low power consumption and reduced heat generation help lower operating costs while supporting long-term performance.

→ Built for Longevity

Flip-Chip COB technology helps slow LED aging, preserving brightness, color accuracy, and dependable performance over time.

03

PRECISION MADE IN KOREA

→ Premium Components

High-quality components are selected to support exceptional visual performance, durability, and long-term reliability.

→ Tight Tolerances

Precision manufacturing helps ensure consistent cabinet alignment, surface flatness, and seamless finished displays.

→ Color Uniformity

Careful manufacturing and calibration deliver consistent color reproduction across modules, cabinets, and the complete display.

→ Made for Demanding Applications

Precision construction creates a platform suited for environments where image consistency and reliability are essential.

Flexible by design

The Pro Indoor Series is available in multiple fine pixel pitch options to support close viewing distances, detailed content, and demanding visual environments.

Available Models: PI09P, PI12P, PI15P (download spec sheet)

Configuration Options: Full HD Bundles, Ultra HD Bundles, Custom Configurations

PI09P PI12P PI15P
Pixel Pitch 0.93mm 1.25mm 1.56mm
Brightness 600 cd/m2 600 cd/m2 600 cd/m2
Contrast Ratio 15,000:1 15,000:1 15,000:1
Color Gamut DCI-P3: 97.9%
Rec. 709: 100%
Rec. 2020: 84.21%
DCI-P3: 97.9%
Rec. 709: 100%
Rec. 2020: 84.21%
DCI-P3: 97.9%
Rec. 709: 100%
Rec. 2020: 84.21%
Viewing Angle H: 178° /
V: 178°
H: 178° /
V: 178°
H: 178° /
V: 178°
Color Bit Up to 22 bit Up to 22 bit Up to 22 bit
Refresh Rate 3840 Hz 3840 Hz 3840 Hz
Pixel Module Dimensions
(W x H x D)
5.9 x 6.64 x 0.1 in. /
150 x 168.75 x 2.7 mm.
5.9 x 6.64 x 0.1 in. /
150 x 168.75 x 2.7 mm.
5.9 x 6.64 x 0.1 in. /
150 x 168.75 x 2.7 mm.
Pixel Module Resolution 160 x 180 px 120 x 135 px 96 x 108 px
Panel Dimensions
(W x H x D)
23.6 x 13.29 x 1.26 in. /
600 x 337.5 x 32 mm.
23.6 x 13.29 x 1.26 in. /
600 x 337.5 x 32 mm.
23.6 x 13.29 x 1.26 in. /
600 x 337.5 x 32 mm.
Weight 9.59 lbs. /
4.35 kg.
9.47 lbs. /
4.3 kg.
9.47 lbs. /
4.3 kg.
Power Consumption
Max per panel 59.74 W 57 W 53.5 W
Max per sqm 295 W 282 W 264 W
Average per panel 20 W 19 W 18 W
Average per sqm 99 W 94 W 88 W
Input voltage AC 100-240V AC 100-240V AC 100-240V
Working temperature -10°C to 45°C -10°C to 45°C -10°C to 45°C
Working humidity 10% to 90% 10% to 90% 10% to 90%
Lifetime 100,000 Hours 100,000 Hours 100,000 Hours

What “Turnkey” Really Means

From early discovery and LED display design through integration, installation, and long-term support, every stage is integrated, documented, and executed to the same uncompromising standard. Nothing is assumed. Nothing is left to chance.
